rev counter wire

[john]

anyone know what wire is for the rev counter on a mk1 berlingo petrol 1.4 (sagem).

autodata show the ecu as 1 plug where as mine has 3, it shows it as 42 going to 426, where my ecu is a row of letters and a row of numbers.

[Gadgetman]

3 plugs?

Pictures or it didn't happen...

[john]

took these before posting (not walking 1/2 a mile to my lock up, sorry).

[Image: IMAG0434.jpg]

[Image: IMAG0433.jpg]

[Image: IMAG0432.jpg]

[Gadgetman]

This is a Mk.I 1.4i ?

You didn't happen to take a picture of the side of that ECU?

[john]

mk1 1.4 as mentioned in my opening post

didn't take a side pic though, why? is it important?

[Gadgetman]

The side typically has a bit of info about which model ECU it is, production date and all that mess.

[john]

ok, im going along later and will get some pics.

[john]

[Image: IMAG0440.jpg]

[Image: IMAG0438.jpg]

[Image: IMAG0437.jpg]

[Image: IMAG0436.jpg]

[addo]

Unplug the battery.
Plug one continuity probe into OBD pin 3
Poke around the dash connector plugs with the other probe
Also poke around the ECU plugs with the other probe

[john]

so is obd3 tacho related?
